Techniks 01620-1/4 DA-200 1/4 Collet

Product Description

The Techniks 01620-1/4 DA-200 1/4 Collet is designed for clamping applications in toolholding. This collet is part of the DA200 series and features a size of one fourth inch. Its clamping range spans from zero point two three four four to zero point two five zero inches, making it suitable for various tasks.

• Clamping range: zero point two three four four to zero point two five zero inches
• Size: one fourth inch (six point three five zero millimeters)
• Brand: Techniks

Product Highlights

This collet is built for precision and reliability in toolholding applications.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: DA200

Technical Specifications

• Size: one fourth inch (six point three five zero millimeters)
• Clamping Range: zero point two three four four to zero point two five zero inches
• Product ID: 200DA-016
• Overall Length: one point one eight eight inches
• Head Diameter: zero point five three one inches
• Suitable For Use With: Double Angle Collet Chuck
