Technical Products SP-200 Potentiostat

Product Description

The Technical Products SP-200 is a potent potentiostat designed for electrochemistry applications. It supports corrosion studies with features like floating mode and analog filtering. This unit includes a built-in calibration board that enhances its usability for precise measurements. Users can choose an optional Ultra-Low Current (ULC) configuration that improves accuracy in readings. The compact design is ideal for in-situ measurements, and the device supports Ethernet and USB connectivity for easy data transfer and monitoring.

• Floating mode and analog filtering for accurate measurements.
• Includes a built-in calibration board for enhanced precision.
• Optional Ultra-Low Current configuration for improved accuracy.

Product Highlights

The Technical Products SP-200 is suitable for diverse electrochemical studies.

Product Information

Standard Information

• Brand: Technical Products
• MPN: SP-200

Technical Specifications

• Electrode connections: 2, 3, 4, 5
• Compliance: ± 12 V
• Acquisition time & timebase: 1 µs with ARG option, 20 µs with EC-Lab developer package, 200 µs with EC-Lab
• Software: EC-Lab, EC-Lab developer package
• Add-ons compatibility: Yes
• Dimension (W x D x H): 167 x 410 x 225 mm
• Weight: 7.2 kg
• Power requirement: 350 W
• Interfaces: Ethernet (Direct, LAN, Wifi), USB 2.0
• Voltage Ranges: Customizable ranges from ± 10 V to ± 30 mV
• Voltage Accuracy: < ± 1 mV ± 0.03 %
• Voltage Measurement Accuracy: < ± 1 mV ± 0.03 %
• Current Ranges: ± 1 A to 10 nA (9 ranges)
• Maximum current: 240 % of range value
• EIS capability: 7 MHz to 10 µHz
