TE CONNECTIVITY Te Connectivity 1SNK505220R0000 Screw Clamp Terminal Block 5.2 mm Spacing (4 Position)
TE CONNECTIVITY Te Connectivity 1SNK505220R0000 Screw Clamp Terminal Block 5.2 mm Spacing (4 Position)

Te Connectivity 1SNK505220R0000 Screw Clamp Terminal Block 5.2 mm Spacing (4 Position)

TE CONNECTIVITY
Brand: TE CONNECTIVITY
SKU: 1SNK505220R0000
Availability: In Stock

Ships same day if ordered by 12 pm
$14.99
$14.99
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The TE Connectivity 1SNK505220R0000 is an Entrelec screw clamp feed-through terminal block for DIN-rail mounting with 5.2 mm spacing and four positions. It features a polyamide housing, operating temperature range of -55 to 110 C, voltage ratings of 300 V (UL/CSA) and 800 V (IEC), and current ratings up to 20 A (UL/CSA) and 29 A (IEC). It accepts AWG 2412 conductors and insulated ferrules, with a 10 mm wire strip length.

  • 4-position feed-through screw clamp terminal block with 5.2 mm pitch and DIN rail (TH35) mounting
  • Electrical ratings: 300 V (UL/CSA), 800 V (IEC), 20 A (UL/CSA)/29 A (IEC); short-time withstand 480 A (1 s)
  • Accommodates flexible conductors AWG 2412 (0.224 mm2) and insulated ferrules AWG 2414 (0.222.5 mm2); 10 mm strip length

Product Highlights

Feed-through screw clamp terminal block, 4 positions, 5.2 mm pitch, DIN rail mounting, -55 to 110 C, 20 A (UL/CSA)/29 A (IEC)

Product Information

Standard Information

  • Brand: TE CONNECTIVITY
  • Manufacturer Part Number: 1SNK505220R0000
Technical Specifications
Manufacturer Part Number
1SNK505220R0000
Brand
TE Connectivity (ENTRELEC)
TE Internal Description
ZS4-D2-BL
Product Type
Screw Clamp Terminal Block
Block Function
Feed-Through
Number of Positions
4
Product Spacing
5.2 mm [0.205 in]
Gauge Type
A3-B3
Housing Material
Polyamide
Primary Product Color
Blue
Mounting Type
DIN Rail
DIN Rail Mounting Type
TH35-15 | TH35-7.5
Voltage Rating (UL/CSA)
300 V
Voltage Rating (IEC)
800 V
Dielectric Withstanding Voltage
2000 V
Impulse Withstanding Voltage (IEC)
8000 V
Current Rating (UL/CSA)
20 A
Current Rating (IEC)
29 A
Short-time Withstanding Current (1 s)
480 A
Power Loss (W)
1.9
Main Circuit Capacity (Flexible Conductor AWG)
24 12
Main Circuit Capacity (Flexible Conductor mm^2)
0.22 4
Main Circuit Capacity (Insulated Ferrule AWG)
24 14
Main Circuit Capacity (Insulated Ferrule mm^2)
0.22 2.5
Wire Stripping Length
10 mm [0.394 in]
Tool Size
3.5 mm [0.138 in]
Operating Temperature Range
-55 to 110 C [-67 to 230 F]
Installation Temperature Range
-5 to 40 C [23 to 104 F]
UL Flammability Rating
UL 94V-0
IP Rating
IP20
Product Weight
15.3 g [0.602 oz]
Dimensions (H x L x D)
70.4 x 65.5 x 65.5 mm
