Te Connectivity 1SNK145041R0000 Marker Card 301->400 Horizontal (1 per Package)

Product Description

TE Connectivity 1SNK145041R0000 is an ENTRELEC MC512PA marker card pre-printed with markings 301 to 400 for horizontal terminal block and strip marking accessories. The card is made of polyamide with a UL 94V-2 flammability rating and an operating temperature range of -55 to 110 °C (-67 to 230 °F). It provides three-digit horizontal markers and is supplied as one card per package.

• Pre-printed marking range 301 to 400 for horizontal terminal identification
• Polyamide construction with UL 94V-2 flammability rating; operating temperature -55 to 110 °C
• Three digits per horizontal marker; pitch 0.205 in (5.20 mm); supplied 1 card per package

Product Highlights

MC512PA master marker card, pre-printed 301–400, horizontal orientation, polyamide, UL 94V-2, -55 to 110 °C, 1 card per package

Product Information

Standard Information

• Brand: TE CONNECTIVITY
• Manufacturer Part Number: 1SNK145041R0000

Technical Specifications

• Brand: TE Connectivity
• Manufacturer Part Number: 1SNK145041R0000
• Product Type: Marker Card
• Model / Series: MC512PA
• Marking Range: 301 -> 400
• Orientation: Horizontal
• Primary Material: Polyamide
• UL Flammability Rating: UL 94V-2
• Operating Temperature Range: -55 to 110 °C (-67 to 230 °F)
• Number of Cards per Package: 1
• Number of Digits per Marker (Horizontal): 3
• Pitch: 0.205 in (5.20 mm)
• Product Weight: 10 g [0.353 oz]
• RoHS Status: ROHS3 Compliant
• Part Status: Active
