Te Connectivity 1SNK145011R0000 Marker Card Horizontal (1 Per Pack)

Product Description

Te Connectivity 1SNK145011R0000 is a horizontal terminal block marker card with pre-printed legends numbered 1 to 100 for SNK series terminal blocks. The card is molded from polyamide, carries a UL 94V-2 flammability rating, and operates from -55 to 110 °C (-67 to 230 °F). Markers present three horizontal digits and compact marker dimensions for clear terminal identification in electrical assemblies.

• Pre-printed legend 1 to 100 for terminal identification
• Horizontal polyamide card with three-digit horizontal markers (marker length 0.197 in, marker width 0.205 in)
• Operating temperature -55 to 110 °C (-67 to 230 °F); UL 94V-2 flammability rating; single card per package

Product Highlights

Horizontal polyamide marker card for SNK series terminal blocks; pre-printed 1–100 legend; compact three-digit markers; RoHS compliant.

Product Information

Standard Information

• Brand: TE CONNECTIVITY
• Manufacturer Part Number: 1SNK145011R0000

Technical Specifications

• Brand: TE Connectivity
• Manufacturer Part Number: 1SNK145011R0000
• Type: Horizontal Marker Card
• Series: SNK / MC512PA
• Legend: 1 -> 100
• For Use With: SNK series terminal blocks
• Orientation: Horizontal
• Material: Polyamide
• Color: White
• Number of Cards per Package: 1
• Number of Digits per Marker - Horizontal: 3
• Marker Length: 0.197 in [5 mm]
• Marker Width: 0.205 in [5.2 mm]
• Operating Temperature Range: -55 to 110 °C (-67 to 230 °F)
• Flammability Rating: UL 94V-2
• Product Weight: 10 g [0.353 oz]
• Product Height: 12 mm [0.472 in]
• Product Length: 5 mm [0.197 in]
• Product Depth: 4.8 mm [0.189 in]
• Product Width: 5.2 mm [0.205 in]
• RoHS Compliance: Yes
• RoHS Phthalates Compliance: Yes
• SVHC: No SVHC (04-Feb-2026)
• ECCN: EAR99
• ERSA Part Number: 384-1SNK145011R0000
• Newark Part Number: 26R3075
• Product Status: Active
