Te Connectivity 1SNA115643R2700 SNA D2.5/6.DPA1 Terminal Block 22 A (6 mm Spacing) Replacement 011564327

Product Description

Te Connectivity 1SNA115643R2700 is an SNA D2.5/6.DPA1 DIN-rail screw clamp terminal block rated 380 V and 22 A with six poles and 6 mm spacing. It accepts 12 AWG conductors with a 6 mm strip length, has a polyamide body, and operates from -55 to 110 °C. The block mounts on TH35 DIN rails and provides screw-clamp terminations for signal and power distribution in control panels and automation systems. Dimensions: 81 mm H x 6 mm W x 43.5 mm L.

• Electrical rating: 380 V, 22 A; six poles, 6 mm pitch; screw-clamp terminal
• Wiring: accepts 12 AWG (0.22–2.5 mm²), 6 mm strip length; tightening torque 0.4 Nm
• Mechanical: DIN-rail mount (TH35-15 | TH35-7.5), polyamide housing, operating temperature -55 to 110 °C

Product Highlights

SNA D2.5/6.DPA1 screw-clamp terminal block, 6 poles, 6 mm pitch, DIN-rail mount

Product Information

Standard Information

• Brand: TE CONNECTIVITY
• Manufacturer Part Number: 1SNA115643R2700
• Country of Origin: France

Technical Specifications

• Manufacturer: TE Connectivity
• Brand: Te Connectivity
• Manufacturer Part Number: 1SNA115643R2700
• Alternate Part Number: 011564327
• Series: SNA
• Type: D2.5/6.DPA1
• Product Type: Terminal Block
• Current Rating: 22 A
• Voltage Rating: 380 V
• Number of Poles: 6
• Connection Type: Screw clamp
• Terminal Type: Screw
• Mounting Type: DIN Rail
• DIN Rail Mounting Type: TH35-15 | TH35-7.5
• Wire Size: 12 AWG (0.22–2.5 mm²)
• Wire Strip Length: 6 mm
• Spacing: 6 mm
• Housing Material: Polyamide
• Operating Temperature Range: -55 to 110 °C
• Dimensions: 81 mm H x 6 mm W x 43.5 mm L
• Product Height: 81 mm
• Product Width: 6 mm
• Product Length: 43.5 mm
• Tightening Torque: 0.4 Nm (3.5 in-lb)
• IP Rating: IP20
• UL Flammability Rating: UL 94V-0
• Application: Signal / power distribution
• Standards/Approvals: UL 94V-0 | IP20 | EU RoHS Directive 2011/65/EU | EU ELV Directive 2000/53/EC | China RoHS 2 Directive MIIT Order No 32, 2016 | EU REACH Regulation (EC) No. 1907/2006 | PROP65
• Product Weight: 16 g
• Unit of Measure: Each
