TB WOODS 8S114 PIPE FITTINGS
TB WOODS 8S114 PIPE FITTINGS

TB Woods 8S114 Sleeve Coupling Flange - Spacer Flange, Size 8, 1.2500 in Bore, Cast Iron Material

TB WOODS
Brand: TB WOODS
SKU: 8S114
Availability: In Stock

Ships same day if ordered by 12 pm

Call for Pricing Call for pricing (215) 326-9845
Call for Pricing Call for pricing (215) 326-9845
Manuals:
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The TB Woods 8S114 is a sleeve coupling flange designed for standard shaft applications. It features a spacer flange for easy installation and a bore size of one point two five inches. Made from high-strength cast iron, this flange ensures durability and reliability in various mechanical power transmission tasks.

  • High-strength cast iron construction
  • 1.2500 inches bore diameter
  • Compatible with CE and FE Series pumps

Product Highlights

This spacer flange is suitable for a range of applications within the mechanical power transmission category.

Product Information

Standard Information

  • Brand: TB Woods
  • MPN: 8S114
Technical Specifications
Bore Diameter
1.2500 in
Flange Diameter
5.4500 in
Length Through Bore
2-3/32 in
Hub Type
Spacer Flange
Hub Material
Cast Iron
Max RPM
4500 rpm
Horsepower @ 100 RPM
1.8 (EPDM & Neoprene) hp, 7.2 (Hytrel) hp
