TB Woods 7JN Neoprene Insert Solid Sleeve

Product Description

The TB Woods Neoprene Insert Solid Sleeve, MPN 7JN, is designed for industrial use. This sleeve is constructed from neoprene material.

• Secure cable protection
• High durability
• Easy to install

Product Highlights

The TB Woods 7JN Neoprene Sleeve is constructed to provide exceptional performance in industrial settings. The sleeve offers secure cable protection and is preferred by engineers and maintenance professionals.

Product Information

Standard Information

• MPN: 7JN
• Brand: TB Woods

Technical Specifications

• Material: Neoprene
• Maximum Speed: 5250 RPM
• Maximum Torque: 940 in-lb
• Outside Diameter: 4 11/32 inches
• Insert Construction: 1-Piece Solid
• Angular Misalignment: 1 degree
• Horsepower @ 100 RPM: 1.5 hp
• Insert Width: 2 3/16 inches
• Parallel Misalignment: 0.02 inches
• Torsional Stiffness: 2769 in-lb/rad
• Application: Blowers, Compressors, Conveyors, Mixers, Motors, Pumps
• Maximum Operating Temperature: 200 degrees F
• Made in: United States
