TB Woods 4JE SFlex JE Coupling Sleeve Insert EPDM Rubber Black

Product Description

Experience high-performance with the TB Woods 4JE SFlex JE Coupling Sleeve Insert. Engineered for robust durability, it is ideal for coupling J or S style flanges. Its EPDM rubber material assures resistance to harsh conditions and maintains torque integrity.

• Supports torque levels up to 120 Inch-lb.
• Designed for RPMs up to 7600.
• Accommodates up to 6.66 horsepower at 3600 Rpm.

Product Highlights

The TB Woods 4JE is an essential component for maintaining operational reliability in high-demand applications such as industrial machinery and HVAC systems. Its ability to adapt to a wide temperature range from 30 degrees to 275 degrees Fahrenheit makes it a versatile choice for diverse operating environments.

Product Information

Standard Information

• Material: EPDM Rubber (Flexible and temperature resistant).
• Color: Black, ensuring discreet integration.

Technical Specifications

• Angular Misalignment: 1 degree maximum.
• Parallel Misalignment: 0.062 Inch maximum.
• Dimensions: Outer Diameter of 2.31 inches, Length of 1.25 inches.
• Compatibility: Use with SFlex coupling flanges for complete assembly.
• Performance: Designed to perform seamlessly up to 7600 RPM with 120 Inch-lb of torque.
