TB Woods 3JE Sleeve EPDM Insert Solid Coupling HVAC Tools

Product Description

The TB Woods 3JE Solid Sleeve Coupling Insert is engineered to provide a reliable connection between J or S style flanges. Ideal for HVAC professionals, this product ensures efficient power transmission.

• Engineered for use with J or S style flanges.
• Maximal torque of 60 inch-pounds at 9200 RPM, translating to 3.28 horsepower at 3600 RPM.
• Temperature endurance from 30 degrees to 275 degrees Fahrenheit.

Product Highlights

Constructed from solid EPDM rubber, TB Woods 3JE is designed for durability and resilience, suitable for demanding industrial settings.

Product Information

Standard Information

• Size: Number 3, 1.88 inches outer diameter, 1 inch overall length
• Color: Black

Technical Specifications

• Material: EPDM Rubber
• Maximum RPM: 9200
• Power Rating: 3.28 hp at 3600 RPM
• Misalignment Tolerance: 1 degree angular, 0.062 inch parallel
