Tasseron THTDFA04 Q-Duct Flange Temperature Sensor 10K Type 2, 4 inches Probe

Product Description

The TASSERON THTDFA04 is a high-quality universal duct temperature sensor with an injection-molded plastic flange and a stainless steel AISI 316 probe. It provides a solution for commercial and industrial applications where a sensor enclosure is not required. Accurate thermistors ensure low drift and are double encapsulated for reliability. Quick Connect wire terminals facilitate easy installation.

• Durable injection-molded plastic mounting flange
• AISI 316 stainless steel temperature probe
• Quick Connect wire terminals

Product Highlights

This duct temperature sensor features a stainless steel probe, quick connect terminals, and is made in the USA. It is suitable for duct temperature and air handling unit applications.

Product Information

Standard Information

• Brand: TASSERON
• Manufacturer Part Number: THTDFA04
• Country of Origin: USA

Technical Specifications

• Type: Thermistor
• Housing Material: Poly
• Probe Length: 4 in
• Sensor Element: 10K Type 2 Thermistor
• Application: Duct Temperature,Air Handling Unit
• Output Signal: Resistance
• Mounting: Injection-molded 30% glass-filled nylon flange with two integrated # 8 mounting holes
• Probe Material: 6mm (± 1/4") AISI 316 stainless steel
• Connection: 2-pole AWG 22-16, 0.35 - 1.5mm2 spring-loaded, Quick Connect wire terminals
• Range: -40-105 Celsius, -40-221 F
• Item Number: THTDFA04
• Brand: TASSERON SENSORS
