Taco I125T4R-1 1-1/4, 4 Way Outdoor Reset I-Series Mixing Valve Threaded Replacement I125T4R-1

Product Description

The Taco I125T4R-1 1-1/4, 4 Way Outdoor Reset I-Series Mixing Valve provides precise and cost-effective temperature control for heating systems. This valve offers the flexibility of zone-to-zone control and built-in boiler protection.

• 1-1/4 inch 4-way injection configurations
• For outdoor reset control or fixed water supply temperature
• Boiler protection against flue gas condensation

Product Highlights

Designed for precise temperature control in heating systems, the Taco I125T4R-1 provides both flexibility and boiler protection. This valve supports multiple configurations and ensures effective management of water supply temperatures.

Product Information

Standard Information

• Brand: Taco
• Model: I125T4R-1

Technical Specifications

• Size: 1-1/4 inches
• Hertz: 60
• Height: 3-15/16 inches
• Application: Hot and Chilled Water, up to 50% Glycol, Closed Systems, Heating
• Body Pattern: 4-Way
• Max Temp: 150°F
• Min Temp: 85°F
• Seat Leakage: Drop-Tight Close Off
• Max Pressure: 300 PSI
• Voltage: 24v
• Amperage: 0.4
• Sensors: NTC Thermistor, 10 k ohm @ 77°F
• Features: Outdoor Reset
• Ambient Conditions: -22°F to 185°F, Indoor Use Only, < 90% Non-Condensing
• Flow Capacity: 9.3 Cv
• Fluid Temperature Range: 20°F to 240°F
• Connection Type: FNPT x FNPT
• Connection Method: Threaded
• Weight: 3.7 lbs
• Width: 2-3/8 inches
• Shipping Depth: 9 inches
• Shipping Width: 9 inches
• Shipping Height: 4 inches
