Taco 335U-075-T1 3/4 Brass Pressure Reducing Valve FNPT Union x FNPT

Product Description

The Taco 335U-075-T1 is a brass pressure reducing valve designed to maintain proper water pressure in heating systems. Its FNPT union inlet connection allows for easy installation. This valve automatically feeds water to the system whenever the pressure falls below the preset level, ensuring optimal operation.

• Fast fill rate enhances system efficiency.
• Includes a built-in check to prevent system emptying if incoming pressure fails.
• Adjustable pressure settings between ten and twenty-five psi for tailored performance.

Product Highlights

This valve is suitable for heating applications and promotes reliability with its dual control features.

Product Information

Standard Information

• Brand: Taco
• Application: Heating

Technical Specifications

• Material: Brass
• Size: 3/4
• Pressure Range: 10 to 25 psi
• Max Inlet Pressure: 100 psi
• Pressure Set Point: Factory set at 12 psi
• Temperature Range: 212°F Max
• Weight: 2.5 lbs
• Dimensions: 3-3/4 x 5-1/8 inches
