T&S Brass B969 Vacuum Breaker 1/2 inches NPT Inlet & Outlet

Product Description

The T&S Brass B969 vacuum breaker features a polished chrome plated brass body with a 1/2" NPT female inlet and outlet. It is certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9, NSF 372 and ASSE 1001. This vacuum breaker is designed for commercial applications.

• Atmospheric vacuum breaker
• Polished chrome plated brass body
• 1/2" NPT female inlet & outlet

Product Highlights

This vacuum breaker is ideal for foodservice, industrial, commercial plumbing and laboratory markets.

Product Information

Standard Information

• Brand: T&S BRASS
• Manufacturer Part Number: B969
• Country of Origin: CHINA

Technical Specifications

• Feature: Atmospheric VB
• Material: Brass Construction
• Pressure Max: 125 psi (8.62 bar)
• Pressure Min: 20 psi (1.38 bar)
• Temperature Max: 180 F (82.22)
• Inlet & Outlet: 1/2" NPT female
• Connector Type: NPT
• Thread Size: 1/2 inch
• Thread Type: NPT
• Size: Small
• Application: Commercial
• Brand Model Compatibility: B0969 Vacuum Breaker
• Color Finish Category: Chromes
• Color Finish Name: Polished Chrome
• End Connection 1: NPT
• End Connections: NPT
• Fitting Size 1: 1/2
• Fitting Sizes: 1/2 in
• GSA Approved: No
• IAPMO Listed: No
• Lead Law Compliance Level: Lead Law Compliant and Certified
• Lead Law Compliant: Yes
• NSF: NSF 372, NSF 61-9
• NSF Certified: Yes
• Trim Only: No
• UPC: 671262175234
• Part #: B-0969
• Part Description: Vacuum Breaker, 1/2 NPT Inlet & Outlet, Atmospheric, Polished Chrome Finish
• Unit of Measure: EA
• Country of Origin: CHINA
• Low Lead Content: Yes
• Inlets: 1/2 NPT Female
• Outlets: 1/2 NPT female
• Engineering Spec: Atmospheric vacuum breaker with polished chrome plated brass body and 1/2 NPT female inlet and outlet. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9, NSF 372 and ASSE 1001.
• Assembled Dimensions - H (In): 2.625
• Assembled Dimensions - W (In): 2
• Assembled Dimensions - D (In): 2
• Primary Product Color: Brass, Silver
• Product Finish: Chrome Plated
• PERFORMANCE 1: Pressure: 20 - 125 psi
• PERFORMANCE 2: Temperature: 40 F - 180 F
• PERFORMANCE 3: Flow Rate: 29.26 GPM @ 60 psi
