SYSTEMAIR 411335 SYSTEMAIR FR 160 Inline Fan 130 W (Size) Replacement MPN

Product Description

The SYSTEMAIR FR 160 Inline Fan (MPN: 411335) is designed for effective air movement in residential and commercial spaces. It features a sealed plastic housing made from UV-protected thermoplastic resin, which makes it suitable for indoor and outdoor installations, including wet areas.

• 100% Speed-controllable
• Prewired with mounting bracket for simple installation
• Approved for residential and commercial use, including wet locations

Product Highlights

This inline fan operates efficiently with an external rotor motor, providing reliable performance across various applications. It is suitable for ventilation in crawl spaces, multiple exhaust points, and can serve as a make-up air supply or booster fan.

Product Information

Standard Information

• Brand: SYSTEMAIR
• MPN: 411335

Technical Specifications

• Voltage: 120 V
• Frequency: 60 Hz
• Phase: 1 ~
• Power: 130 W
• Current: 1.14 A
• Max. airflow: 299 cfm
• Fan impeller speed: 2540 r.p.m.
• Max. temperature of transported air: 140 °F
• Insulation class, motor: B
• Enclosure class, motor: 44 IP
• Weight: 8 lbs
• Dimensions: 6 1/4 x 11 3/4 x 5 7/8 inches
