System Sensor P2GRKLED L-Series outdoor compact wall-mounted horn strobe 16-33 VDC (compact wall) P2RK

SYSTEM SENSOR
Brand: SYSTEM SENSOR
SKU: P2GRKLED
Availability: In Stock

Ships same day if ordered by 12 pm
$124.86
$124.86
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The System Sensor P2GRKLED is an L-Series outdoor compact wall-mounted horn strobe that provides audible and visible notification using an LED strobe and integrated horn. It is rated NEMA 4X and IP56 as a standalone device, operates across 16–33 VDC, and offers field-selectable candela settings with rotary switches for candela, tone, and volume. The unit is designed for wall mounting with a universal mounting plate and onboard shorting spring.

  • LED strobe with approximately 60% lower current draw versus previous generation, improving NAC design flexibility
  • Field-selectable candela settings (15, 30, 75, 95, 110, 115, 135, 150, 177, 185 cd) and rotary switches for tone and volume
  • Weatherproof NEMA 4X/IP56 rating, operating range −40°F to 151°F, universal mounting plate with onboard shorting spring

Product Highlights

Outdoor L-Series horn strobe; 16–33 VDC input; selectable candela; NEMA 4X/IP56; retrofit compatible with legacy SpectrAlert and SpectrAlert Advance

Product Information

Standard Information

  • Brand: SYSTEM SENSOR
  • Manufacturer Part Number: P2GRKLED
  • Country of Origin: Mexico
Technical Specifications
Brand
System Sensor
Manufacturer Part Number
P2GRKLED
Series
L-Series Outdoor
Product Type
Outdoor compact wall-mounted horn strobe
Mounting Type
Wall (universal mounting plate; listed for ceiling or wall mounting)
Input Voltage
16–33 VDC
Candela Settings
15, 30, 75, 95, 110, 115, 135, 150, 177, 185 cd
Horn Rating
88+ dBA at 16 volts
Environmental Rating
NEMA 4X, IP56 (standalone device)
Operating Temperature
-40°F to 151°F
Design/Construction
Plug-in design with minimal intrusion into back box; tamper-resistant construction; weatherproof backbox for in-and-out wiring
Mounting Features
Universal mounting plate with onboard shorting spring for wiring continuity testing
Synchronization
Compatible with System Sensor synchronization protocol; supports synchronization via System Sensor Sync or MDL Sync Module
Compatibility
Electrically compatible with legacy System Sensor SpectrAlert and SpectrAlert Advance devices
Certifications
UL, ULC; FM; CSFM
Dimensions
5.84 x 3.76 x 1.87 in
Weight
0.6 lbs
Replacement For
P2RK
Country of Origin
Mexico
UPC
783863060038
