SYLVANIA QHE4X54T5HOUNVPSNHTSCLDOE Electronic Fluorescent Ballast

Product Description

The Sylvania QHE4X54T5HOUNVPSNHTSCLDOE is an electronic ballast suitable for fluorescent lamps. It supports up to four lamp configurations and operates with a voltage range of 120 to 277 volts AC. The ballast includes a programmed rapid start function and is designed to perform in high ambient temperatures.

• Compatible with FP54T5HO lamp types.
• High efficiency with over 90% efficiency rating.
• Operates well in temperatures from minus 29 degrees Celsius to 90 degrees Celsius.

Product Highlights

This electronic ballast is ideal for use in commercial and industrial settings where multiple lamp applications are needed.

Product Information

Standard Information

• Brand: SYLVANIA
• MPN: QHE4X54T5HOUNVPSNHTSCLDOE

Technical Specifications

• Input Voltage: 120-277V AC ±10%
• Wattage: 54
• Lamp Type: (1-4) F54T5/HO, (1-4) F54T5/HO/ES (49W), (1-4) F58T5, (1-4) FT36W/2G11, (1-4) FT50W/2G11, (1-4) FT55W/G11
• Number of Lamps: 1, 2, 3, 4
• Ballast Factor: 1.00
• Operating Temperature: -29°C to 90°C
• Efficiency: >90%
• Switching Cycles: 100,000+
• Dimensions: 16.73 inches (L) x 1.68 inches (W) x 1.18 inches (H)
• Certifications: UL CC, CSA, FCC, RoHS, DOE
