SURGE PROTECTION 83915 Surge Protection 83915 60 Amp Non-Fusible Disconnect Switch with Surge Module

Product Description

The SURGE PROTECTION 83915 is a 60 Amp, 2-pole, pull-out non-fusible disconnect switch designed with an integrated internal surge protector. This product enables quick installation and features a robust metal weather-resistant enclosure suited for outdoor use. The device includes thermally protected MOVs that safeguard your HVAC components against power surges. Additionally, external LED indicators keep users informed of the operational status.

• Integrated internal surge protector for enhanced safety.
• Durable metal weather-resistant enclosure.
• External LED indicators for easy monitoring.

Product Highlights

This disconnect switch offers reliability and protection, making it ideal for HVAC systems.

Product Information

Standard Information

• Brand: SURGE PROTECTION
• MPN: 83915

Technical Specifications

• Type: Pull-Out Non-Fusible Disconnect Switch with Surge Module
• Amp Rating: 60 Amp
• Number of Poles: 2-Pole
• Product Voltage: 240 VAC
• Material: Steel
• Product Depth: 2.25 inches
• Product Height: 8.66 inches
• Product Width: 5.12 inches
• Enclosure Type: NEMA 3R
• Frequency Rating: 50/60 Hz
• Indicator Type: LED
• Modes of Protection: L1/L2/L/N-G
• Phase: 1 ph
• Voltage: 120/240 VAC
• Opening: Side
