Suntec OSVA38 Oil Safety Valve 3/8 in FPT 2P396

Product Description

The Suntec OSVA38 oil safety valve provides automatic shutoff for oil supply systems, designed for inlet pressures up to 60 PSI and a maximum outlet pressure of 3 PSI. It prevents fuel from entering the building if the line between the device and the burner breaks, relieves pressure strain on burner pump inlets, and is recommended for in-line mounting ahead of Webster SPM series supply pumps. Connection size is 3/8 in FPT and flow should not exceed 60 GPH.

• Automatically shuts off oil supply if the line between the device and the burner breaks to prevent fuel entry to the building
• Maximum inlet pressure 60 PSI, maximum outlet pressure 3 PSI, and maximum flow rate 60 GPH
• 3/8 in FPT connection with in-line mounting recommended; suited for installation upstream of Webster SPM series supply pumps

Product Highlights

Max inlet 60 PSI; max outlet 3 PSI; 3/8 in FPT; max flow 60 GPH; in-line mounting; recommended before Webster SPM series pumps

Product Information

Standard Information

• Brand: SUNTEC
• Manufacturer Part Number: OSVA38

Technical Specifications

• Brand: Suntec (Webster Fuel Pumps & Valves)
• Manufacturer Part Number: OSVA38
• Replacement Part Number: 2P396
• Connection Size: 3/8 in FPT
• Maximum Inlet Pressure: 60 PSI
• Maximum Outlet Pressure: 3 PSI
• Maximum Flow Rate: 60 GPH
• Mounting Type: In-line
• Recommended Application: Installation prior to burner pump(s) on Webster SPM series supply pump installations
