Suntec J4PCC10008MUCSPC Gear Pump J4 1000 400-3000 kW

Product Description

The SUNTEC J4PCC10008MUCSPC is a gear pump designed for medium capacity oil burners, suitable for systems ranging from 400 to 3000 kW. It handles fuel oil #4 and lighter, plus B6-B20 biodiesel blends, operating in one or two-pipe systems. This pump features a pressure regulating valve and flange mounting according to EN 225. It supports an operating viscosity of 2 to 75 mm²/s (cSt) and oil temperatures from 32 to 194°F.

• Designed for medium capacity oil burners (400 to 3000 kW).
• Compatible with fuel oil #4, lighter fuels, and B6-B20 biodiesel blends.
• Features a pressure regulating valve and EN 225 flange mounting.

Product Highlights

Versatile gear pump for oil burners, supporting various fuel types and system configurations with integrated pressure regulation.

Product Information

Standard Information

• Brand: SUNTEC
• Manufacturer Part Number: J4PCC10008MUCSPC

Technical Specifications

• Category: Pumps
• Sub-Category: Motor Driven Pump
• Application: Oil burners with capacities from 400 to 3000 kW
• Fuel Compatibility: Fuel oil #4 and lighter, B6-B20 biodiesel blends
• System Type: One or two-pipe systems
• Pressure Regulation: Integrated valve
• Cut-off Function: Available with or without
• Mounting Type: Flange mounting according to EN 225
• Connection Threads: Inlet/Return: 1/4 NPTF (conical); Nozzle Outlet: 1/8 NPTF; Pressure Gauge Port: 1/8 NPSF; Vacuum Gauge Port: 1/4 NPTF
• Operating Viscosity: 2 - 75 mm²/s (cSt)
• Oil Temperature Range: 32 - 194°F
• Max Inlet Pressure: 10 psi (NFPA limits to 3 psi max)
• Max Return Pressure: 10 psi (NFPA limits to 3 psi max)
• Max Suction Height: 6.5 psi max vacuum
• Rated Speed: 3600 rpm max
• Weight: 8.8 lbs
