Suntec Industries A1YA-7912 Oil Suntec A1YA-7912 Pump

Product Description

The SUNTEC INDUSTRIES A1YA-7912 is a single-stage oil burner pump used on oil burners. It features a strainer and nozzle rating of 7 GPH at 100 PSI and a speed rating of 1725 RPM. This model is designed for residential and light commercial oil burners and is rated for use with biofuels and standard No. 2 fuel oil.

• 1-Pipe Installation to 6 Inch Hg Vacuum
• 2-Pipe Installation to 12 Inch Hg Vacuum
• Lift or Gravity Feed Application with 10 PSI Maximum Inlet/Return Pressure

Product Highlights

The SUNTEC INDUSTRIES A1YA-7912 is ideal for burners that require compatibility with renewable fuels, supporting cleaner-burning applications without sacrificing performance.

Product Information

Standard Information

• Brand: SUNTEC INDUSTRIES
• Manufacturer Part Number: A1YA-7912
• Country of Origin: USA

Technical Specifications

• Manufacturer Part Number: A1YA-7912
• Series/Model: A-7000
• Item: Pump, 1-Stage
• Used On: Oil Burner
• Speed Rating: 1725 RPM
• Strainer capacity: 7 GPH
• Max GPM: 7
• Max PSI: 100
• Max Temperature: 115 degrees F
• RPM: 1725
• Shaft Diameter: 5/16 inch
• Motor speed: 1725 RPM
• Shaft rotation: Clockwise
• Nozzle Location: R.H.
• Flow Rate: 7.0 GPH
• Number of Stage: Single-Stage
• Pump Rotation: R.H.
• Maximum Operating Pressure: 100 psi
• Mount Position: Any Position
• Pump Speed: 1725 RPM
• Application: Heating Systems
• Approval: cUL listed
• Recommended motor frequency: 60 Hz
• Inlet Port: 1/4 inch
