Summit Appliance AL54IF 24 inches Wide Built-In All-Refrigerator, ADA Compliant

Product Description

The SUMMIT APPLIANCE AL54IF is a 24" wide built-in undercounter all-refrigerator, designed for ADA compliant kitchens. This unit features frost-free operation with fan-forced cooling for even temperature distribution and low maintenance. It has a 4.4 cu.ft. capacity and a digital thermostat for precise temperature management, ranging from 36 to 43°F. The panel-ready design allows for custom integration into cabinetry, while its front-breathing system enables built-in installation with minimum clearance. It operates on 115 V AC/60 Hz.

• Frost-free operation with fan-forced cooling ensures low maintenance and even temperature distribution.
• Digital thermostat for precise temperature management and recessed LED lighting for efficient illumination.
• ADA compliant 32" height and panel-ready design for seamless undercounter integration.

Product Highlights

This ADA compliant 24" all-refrigerator offers frost-free cooling, digital temperature control, and a panel-ready design for custom kitchen integration.

Product Information

Standard Information

• Brand: SUMMIT APPLIANCE
• Manufacturer Part Number: AL54IF

Technical Specifications

• Nominal Height: 32.0" (81 cm)
• Cabinet Height: 32.0" (81 cm)
• Nominal Width: 24.0" (61 cm)
• Overall Width: 23.38" (59 cm)
• Nominal Depth: 23.0" (58 cm)
• Overall Depth: 22.63" (57 cm)
• Depth with Door Open 90 Degrees: 46.0" (117 cm)
• Capacity: 4.4 cu.ft. (125 L)
• Defrost Type: Frost-Free
• Door Style: Panel-Ready
• Cabinet Color: Black
• US Electrical Safety Certification: ETL
• Canadian Electrical Safety Certification: ETL-C
• Annual Energy Consumption: 270.0 kWh/year
• Amperage: 1.0
• Voltage/Frequency: 115 V AC/60 Hz
• Product Weight: 100.0 lbs. (45 kg)
• Sabbath Mode: Yes
• Door Hinge Side: RHD
• Door Reversible: Yes
• Shelf Material: Glass
• Number of Shelves: 3
• Number of Full Door Shelves: 2
• Adjustable Shelves: Yes
• Thermostat Type: Digital
• Fan Type: Interior and Exterior
• Refrigerant Type: R600a
• Refrigerant Amount: 0.99 oz.
• High Side Pressure (PSI): 270.0
• Low Side Pressure (PSI): 105.0
• Number of Leveling Legs: 4
• Interior Light: Yes
• Temperature Range: 36 to 43°F
• Sound Level: 33.3 dB
• Interior Height: 24.38" (62 cm)
• Interior Width: 20.0" (51 cm)
• Interior Depth: 16.63" (42 cm)
• Compressor Step Height: 3.25" (8 cm)
• Compressor Step Width: 20.0" (51 cm)
• Compressor Step Depth: 5.25" (13 cm)
• Overlay Panel Dimensions (W x H): 23.4 inches x 28.38 inches
• Maximum Overlay Panel Weight: 10 lbs
