Sugatsune MC-JM45WT Magnetic Cabinet Catch White

Product Description

The SUGATSUNE MC-JM45WT is a plastic-cased magnet catch designed for cabinet and door closure applications in residential and light commercial millwork. The catch body is molded from polyacetal with an integrated neodymium magnet and a 316 stainless steel insert, delivering a rated magnetic force of 9.9 pounds in a compact form factor. The assembled catch measures 1-25/32 inches long, 43/64 inches wide, and 7/32 inches high. A matching strike plate is included, measuring 15/16 inches long by 19/32 inches wide. The white finish suits painted cabinetry and furniture interiors. This type of hardware is typically installed by finish carpenters, cabinetmakers, and millwork contractors.

The MC-JM45WT is suited for overlay and inset cabinet doors, furniture cases, and light-duty enclosure lids where a low-profile, corrosion-resistant magnetic latch is required. The polyacetal body resists moisture and common household chemicals, making it appropriate for kitchen, bath, and marine-adjacent cabinetry where 316 stainless components are specified for corrosion resistance. The compact height of 7/32 inches minimizes surface projection inside the cabinet case.

Key Features

• Neodymium magnet delivers 9.9 pounds of magnetic retention force
• Polyacetal (POM) body resists moisture and chemical exposure
• 316 stainless steel construction on internal components for corrosion resistance
• White finish integrates with painted and white-laminate cabinetry
• Low-profile body at 7/32 inches high minimizes interference inside cabinet cases
• Includes matching strike plate: 15/16 inches long by 19/32 inches wide

Compatibility

Designed as an OEM-style magnetic catch for residential and light commercial cabinet doors and furniture enclosures requiring a compact, low-profile latch with a white finish.

Installation Notes

Installation is typically performed by finish carpenters or cabinetmakers using basic hand tools. Locate and fasten the catch body to the cabinet frame and position the strike plate on the door face to ensure flush magnetic contact when the door is closed. Power tools are not required, but a drill and appropriate pilot bit are recommended to avoid splitting the mounting substrate. No electrical shutoff is required for this hardware installation.
