Sugatsune HH-FB-2/S Recessed Pull Satin M4 Stud

Product Description

The SUGATSUNE HH-FB-2/S is a recessed sheet metal pull designed for flush-mount installation in panel doors, access hatches, enclosures, and equipment cabinets. Constructed from 304 stainless steel with a satin finish, this pull sits flush within a machined recess to keep hardware profiles low and reduce snag points. The overall width measures 109.5mm (approximately 4.31 inches) and overall height measures 64mm (approximately 2.52 inches), with a recess depth of 14.5mm (approximately 0.57 inches). Mounting is secured via an M4 threaded stud. This hardware is suited for sheet metal fabricators, enclosure builders, and maintenance technicians working on industrial or commercial panel assemblies.

This recessed pull is commonly specified for electrical enclosures, HVAC access panels, control cabinets, and similar sheet metal assemblies where a low-profile handle is required. The satin stainless finish provides corrosion resistance in moderate-exposure environments. The 88mm center-to-center dimension and 67.5mm recess width fit standard cutout templates used in light industrial sheet metal work. Installation requires a precise cutout matching the recess dimensions, making it appropriate for fabricated enclosures built to spec rather than retrofit field applications.

Key Features

• 304 stainless steel construction with satin finish for corrosion resistance
• Overall width of 109.5mm (approximately 4.31 inches) and overall height of 64mm (approximately 2.52 inches)
• Recess depth of 14.5mm (approximately 0.57 inches) with recess height of 40mm and recess width of 67.5mm
• 88mm center-to-center mounting dimension
• M4 threaded stud for secure panel attachment
• Flush recessed profile minimizes protrusion on finished panel surfaces

Compatibility

Designed as an OEM-style recessed pull for sheet metal enclosures, access panels, and equipment cabinets requiring a flush-mount M4 stud hardware solution.

Installation Notes

Installation is typically performed during enclosure fabrication or panel assembly. A precise cutout matching the recess width and height dimensions is required before mounting. Power down and de-energize any enclosure before servicing or replacing panel hardware. Use appropriate M4 fasteners and verify thread engagement depth to ensure a secure, rattle-free mount.
