Studor 20341 Mini-Vent Air Admittance Valve for 1-1/2 to 2 PVC

Product Description

The Studor 20341 Mini-Vent Air Admittance Valve provides a reliable solution for venting in residential and commercial plumbing systems. It is compatible with pipes sized at one and one-half inches or two inches. This valve utilizes a male threaded inlet connection and includes a PVC adapter for easy installation.

• Designed for residential and commercial applications
• Opens automatically to allow air intake under negative pressure
• Closes naturally when the water flow stops to prevent odors

Product Highlights

This valve effectively vents up to twenty DFUs on a horizontal branch and twenty-four DFUs on a stack. It helps maintain water seals in traps without the need for costly roof penetrations.

Product Information

Standard Information

• Brand: Studor
• MPN: 20341

Technical Specifications

• Applicable Standard: ANSI/ASSE 1050/1051, NSF 14, ICC-ES PMG-1025, C-IAPMO
• Application: Residential, Commercial
• Inlet Size: 1-1/2 Inch or 2 Inch
• Inlet Connection: Male Threaded
• Inclusions/Features: PVC Adapter
• Product Type: Hydronics
• Product Sub-Type: Vent Valve
• Commodity Code Description Level 3: Pressure and Temperature Control Valves
