Storm ASBU10Y Brass Anti-siphon Body with Union 1 Inch

Product Description

The STORM ASBU10Y is a 1-inch brass anti-siphon body with union, designed to prevent backflow and protect potable water supplies from contamination caused by back-siphonage. This fitting incorporates a union connection for easier in-line installation and serviceability without cutting pipe. Built from brass construction, it is suited for use in irrigation, plumbing, and water distribution systems where backflow prevention at a valve or outlet is required. Licensed plumbers and irrigation technicians are the primary installers of this type of device in both residential and light commercial settings.

The ASBU10Y anti-siphon body with union is typically installed at hose bibs, irrigation control valves, and service connections where a backflow prevention device is required by local plumbing code. The 1-inch size makes it compatible with standard 1-inch pipe runs in residential irrigation manifolds and service line branches. Its union fitting allows the body to be removed and serviced or replaced without disturbing adjacent piping.

Key Features

• Brass construction for corrosion resistance and durability in wet service environments
• Anti-siphon design prevents back-siphonage and protects potable water supplies
• Integrated union connection simplifies installation and future serviceability
• 1-inch pipe size fits standard residential and light commercial irrigation and plumbing applications

Compatibility

Designed as an OEM-style replacement or direct-install anti-siphon valve body for 1-inch plumbing and irrigation systems requiring backflow prevention at the point of connection.

Installation Notes

Installation should be performed by a licensed plumber or certified irrigation technician in accordance with local plumbing codes and the applicable International Plumbing Code requirements for backflow prevention devices. Shut off the water supply and relieve line pressure before removing any existing valve or fitting. The union connection should be hand-tightened first, then snugged with a wrench using appropriate thread sealant or tape on threaded connections. Verify the anti-siphon device is oriented correctly per the flow direction marked on the body before returning the system to service.

Technical Specifications

• Material: Brass
• Connection Size: 1 inch
• Connection Type: Union

Standard Information

• Brand: STORM
• Manufacturer Part Number: ASBU10Y
