Product Description
The SteelCrest BTU16X16RWHH is a fixed-blade return air grille constructed from solid steel with a white powder-coat finish. It is designed for use in residential and light commercial HVAC systems where a return air pathway is needed through a wall or ceiling surface. The slotted face pattern supports consistent airflow back to the air handler or furnace while providing a clean, finished appearance. The grille fits a 16 x 16 inch duct opening and installs with an overall face size of 18 x 18 inches, covering the rough opening and surrounding drywall edge. Licensed HVAC technicians and skilled remodelers typically handle this installation during new construction or system upgrades.
This return grille is suited for wall or ceiling applications in residential new construction, renovation projects, and direct-replacement scenarios where an existing 16 x 16 inch return duct opening is present. The 18 x 18 inch face plate overlaps the duct opening border, eliminating the need for additional trim work. The fixed-blade design means no movable parts, reducing long-term maintenance needs in high-use return air locations.
Key Features
- Solid steel construction with white powder-coat finish for long-term durability
- Fixed slotted blade design promotes steady, unrestricted return airflow
- Fits 16 x 16 inch duct opening with an 18 x 18 inch overall face size
- Suitable for both wall and ceiling mount installations
- Direct-replacement design simplifies new construction and remodel installs
Compatibility
Designed as a direct-replacement fixed return grille for residential and light commercial HVAC systems with a 16 x 16 inch return air duct opening in wall or ceiling applications.
Installation Notes
Installation is typically performed by a licensed HVAC technician or qualified contractor. Shut down the HVAC system at the thermostat and disconnect power at the breaker before beginning work. Verify the rough duct opening measures 16 x 16 inches before mounting to ensure proper seating of the 18 x 18 inch face plate. Secure the grille using fasteners appropriate for the wall or ceiling substrate material.
Technical Specifications
-
Duct Opening Size: 16 x 16 inches
-
Overall Face Size: 18 x 18 inches
-
Material: Solid Steel
-
Finish: White Powder Coat
-
Blade Type: Fixed Slotted
-
Mount Type: Wall or Ceiling
-
Package Weight: 14 pounds
-
Package Dimensions: 20 x 20 x 4 inches
Standard Information
-
Brand: SteelCrest
-
Manufacturer Part Number: BTU16X16RWHH
