Product Description
The SteelCrest BTU12X8RWHH is a fixed-blade return air grille designed for wall and ceiling installations in residential and light commercial HVAC systems. Constructed from solid steel with a white powder-coat finish, it features a slotted face design that supports consistent return airflow back to the air handler or furnace. The grille fits a 12x8 inch duct opening and installs with an overall finished face size of 14x10 inches, covering the rough opening cleanly without additional trim work. HVAC technicians and finishing contractors install this grille during new construction and remodel projects where a clean, durable register face is required.
This grille is suited for return air applications in residential homes, apartments, and light commercial spaces. It mounts flush to drywall or ceiling surfaces over a standard 12x8 inch duct collar. The fixed-blade, non-adjustable face makes it appropriate for return air only, not supply. The white powder-coat finish blends with standard interior trim and holds up to regular cleaning without chipping or peeling under normal indoor conditions.
Key Features
- Solid steel construction with white powder-coat finish for long-term durability
- Fixed slotted face design optimized for return air applications
- Fits 12x8 inch duct opening with a 14x10 inch finished face size
- Suitable for both wall and ceiling mounting
- Direct-replacement fit simplifies installation in new construction and remodel applications
Compatibility
Designed as a direct-replacement fixed return air grille for standard 12x8 inch duct openings in residential and light commercial HVAC return air systems.
Installation Notes
Installation is typically performed by an HVAC technician or finishing contractor. Power down the HVAC system at the thermostat or disconnect before accessing the duct opening. Confirm the duct rough opening measures 12x8 inches before mounting. Secure the grille to the wall or ceiling surface using appropriate fasteners for the substrate material.
Technical Specifications
-
Duct Opening Size: 12x8 inches
-
Overall Finished Face Size: 14x10 inches
-
Material: Solid Steel
-
Finish: White Powder Coat
-
Mounting Location: Wall or Ceiling
-
Airflow Application: Return Air (Fixed, Non-Adjustable)
-
Package Weight: 4 pounds
-
Package Dimensions: 16x12x3 inches
Standard Information
-
Brand: SteelCrest
-
Manufacturer Part Number: BTU12X8RWHH
