Product Description
The SteelCrest BTU12X12RWHH is a fixed return air grille designed for wall and ceiling installation in residential and light commercial HVAC systems. Constructed from solid steel with a white powder-coat finish, it features a slotted face pattern that supports consistent return airflow while maintaining a clean, finished appearance. The grille fits a 12 x 12 inch duct opening and installs with an overall face size of 14 x 14 inches, covering the rough opening neatly without additional trim work. Licensed HVAC technicians and experienced contractors install this type of grille during new construction, system upgrades, and remodels.
This return grille is suited for residential and light commercial applications where a fixed, non-adjustable return air opening is required. It mounts flush to drywall or ceiling surfaces over a standard 12 x 12 inch duct collar. The powder-coat finish resists chipping and corrosion in typical conditioned-space environments. Its direct-replacement dimensions make it a straightforward swap for worn or damaged existing grilles without modification to the duct opening.
Key Features
- Solid steel construction with white powder-coat finish for long-term durability
- Slotted face pattern promotes steady return airflow distribution
- Fits standard 12 x 12 inch duct opening with a 14 x 14 inch overall face size
- Fixed blade design — no adjustable louvers to misalign or break over time
- Suitable for both wall and ceiling installation
Compatibility
Designed as a direct-replacement return air grille for standard residential and light commercial duct systems with a 12 x 12 inch return air opening.
Installation Notes
Installation is performed by licensed HVAC technicians or qualified contractors. Power down the air handler or furnace at the disconnect before removing an existing grille or accessing the duct. Confirm the rough duct opening measures 12 x 12 inches before ordering to ensure correct fit. Secure the grille to the wall or ceiling surface using fasteners appropriate for the substrate — do not rely on friction fit alone.
Technical Specifications
-
Duct Opening Size: 12 x 12 inches
-
Overall Face Size: 14 x 14 inches
-
Material: Solid Steel
-
Finish: White Powder Coat
-
Grille Type: Fixed Return
-
Mount Location: Wall or Ceiling
-
Package Weight: 12 pounds
-
Package Dimensions: 16 x 16 x 4 inches
Standard Information
-
Brand: SteelCrest
-
Manufacturer Part Number: BTU12X12RWHH
