Product Description
The SteelCrest BTU10X2.25SWHH is a slotted supply vent with an integrated damper, designed for installation in walls and ceilings as part of a residential or light-commercial HVAC distribution system. It is built from solid steel with a white powder-coat finish, giving it long-term corrosion resistance and a clean appearance suited to modern and traditional interiors alike. The vent fits a 10 x 2.25 inch duct opening and installs with an overall face size of 12 x 4.25 inches, covering rough framing edges cleanly. The built-in damper allows the technician or installer to adjust airflow volume at the register without returning to the air handler. HVAC installers and remodelers use this register for both new construction and retrofit applications.
This supply vent is suited for forced-air heating and cooling systems where a slim, low-profile register is required. The 10 x 2.25 inch duct size is common in floor, wall, and ceiling runs where space is limited, such as under windows, in toe kicks, or along narrow soffits. The finished 12 x 4.25 inch face overlaps the duct opening to provide a finished look without additional trim work. The slotted face pattern supports directional airflow diffusion across the conditioned space. It is appropriate for both new construction rough-in and direct-replacement upgrades during remodels or system retrofits.
Key Features
- Solid steel construction with white powder-coat finish for durability and corrosion resistance
- Integrated damper allows on-site airflow adjustment without additional components
- Fits a 10 x 2.25 inch duct opening with a 12 x 4.25 inch overall face size for clean overlap
- Slotted face design provides diffused airflow distribution
- Suitable for wall and ceiling installation in forced-air HVAC systems
- Direct-replacement fit for fast installation in new construction or remodel projects
Compatibility
Designed as a direct-replacement supply register for forced-air HVAC systems using a 10 x 2.25 inch duct opening in residential and light-commercial wall or ceiling applications.
Installation Notes
Installation is typically performed by an HVAC technician or general contractor during rough-in or finish work. Turn off the air handler or furnace before removing an existing register to prevent debris from entering the duct system. Secure the grille to the surrounding wall or ceiling surface per the manufacturer fastening method, ensuring the face plate fully overlaps the duct opening. Verify the damper blade moves freely and seats properly before restoring system operation.
Technical Specifications
-
Duct Opening Size: 10 x 2.25 inches
-
Overall Face Size: 12 x 4.25 inches
-
Material: Solid steel with white powder-coat finish
-
Damper: Integrated
-
Installation Location: Wall or ceiling
-
Package Weight: 3 pounds
-
Package Dimensions: 14 x 7 x 3 inches
-
Minimum Order Quantity: 1
Standard Information
-
Brand: SteelCrest
-
Manufacturer Part Number: BTU10X2.25SWHH
