SteelCrest BTU10X2.25RORBH Fixed Return Grille 10x2.25

Product Description

The SteelCrest BTU10X2.25RORBH is a fixed-blade return air grille designed for wall and ceiling installations in residential and light commercial HVAC systems. Constructed from solid steel with an oil-rubbed bronze powder-coat finish, this slotted decorative grille fits a 10 x 2.25 inch duct opening and installs with an overall face size of 12 x 4.25 inches. The fixed-blade design supports consistent airflow through the return air path while providing a finished, architectural appearance. HVAC technicians and remodeling contractors rely on this style of grille for new construction and retrofit applications where a refined aesthetic is required alongside functional performance.

This grille is suited for residential and light commercial HVAC return air applications mounted to drywall, plaster, or wood-framed walls and ceilings. The 10 x 2.25 inch duct opening size targets narrow-profile return runs common in baseboard-level and floor-joist applications. The direct-replacement design and standard face dimensions make it practical for remodel work where an existing grille needs to be swapped without modifying the duct opening. Licensed HVAC technicians and general contractors commonly specify this grille during system upgrades or finish-out phases of construction.

Key Features

• Solid steel construction with oil-rubbed bronze powder-coat finish for long-term durability
• Fits a 10 x 2.25 inch duct opening with a finished face size of 12 x 4.25 inches
• Fixed-blade slotted design supports steady return airflow
• Suitable for wall or ceiling mount installations
• Direct-replacement sizing simplifies new construction and remodel installs

Compatibility

Designed as a direct-replacement fixed return grille for residential and light commercial HVAC systems with a 10 x 2.25 inch return air duct opening.

Installation Notes

Installation is typically performed by a licensed HVAC technician or qualified contractor. Turn off the HVAC system at the thermostat and disconnect power at the air handler before beginning work. Secure the grille to the wall or ceiling surface using fasteners appropriate for the substrate — drywall, plaster, or wood framing. Do not obstruct the duct opening with mounting hardware, and verify the duct collar edge is clean and flush before fastening the grille face.

Technical Specifications

• Duct Opening Size: 10 x 2.25 inches
• Overall Face Size: 12 x 4.25 inches
• Material: Solid steel
• Finish: Oil-rubbed bronze powder coat
• Blade Type: Fixed slotted
• Mount Type: Wall or ceiling
• Package Weight: 3 pounds
• Package Dimensions: 14 x 7 x 3 inches

Standard Information

• Brand: SteelCrest
• Manufacturer Part Number: BTU10X2.25RORBH
