State Water Heaters GS6-75-CRRS ProLine 74-Gallon Water Heater 75,100 BTU

Product Description

The STATE WATER HEATERS GS6-75-CRRS ProLine® 74-Gallon High-Recovery Atmospheric Vent Liquid Propane Water Heater features a 75,100 BTU propane burner with a first-hour rating of 125 gallons and a recovery rate up to 81 gallons per hour. It has a thermal efficiency of 80% and a Uniform Energy Factor of 0.60.

• Delivers a 125-gallon first hour rating to meet hot water demands.
• Eco-Friendly Design reduces NOx emissions by up to 33%.
• Features DynaClean™ automatic cleaning system protects against sediment build-up.

Product Highlights

This ProLine® water heater features advanced tank protection, including a stainless steel CoreGard™ anode rod and Blue Diamond® glass lining.

Product Information

Standard Information

• Brand: STATE WATER HEATERS
• Manufacturer Part Number: GS6-75-CRRS
• Country of Origin: US

Technical Specifications

• Nominal Gallon Capacity: 74 Gallons
• Rated Storage Volume: 71 Gallons
• UEF: 0.6
• Thermal Efficiency: 80%
• Maximum BTUs: 75,100
• Power Source: GAS
• T&P Relief Valve: Yes
• Water Connection Location: TOP
• Water Connection Size: 1"
• Emissions: Low NOx
• First Hour Rating: 125 Gallons
• ASME Certified: No
• Blanket Included: No
• Destination Country: US
• Flue Diameter: 5.00
• Fuel Source: PROPANE
• Ignition Type: Pilot with Piezo Igniter
• Installation Type: INDOOR
• Application: RESIDENTIAL
• Side Loop: No
• Type: Water Heater
• Height: 57"
• Diameter: 26.39"
• Vent Type: Atmospheric Vent
• Fuel Type: Liquid Propane
• Tankless: No
• Tank Size (Gallons): 74
• Building Type: Residential
• Water Heater Height (inches): 57
• Diameter/Width (inches): 26.5
• Water Inlet Size: 1 Male
• Gas Connection (inches): 1/2
• Vent Size (inches): 4
• Height Including Draft Hood (inches): 61
• Approximate Weight (pounds): 275
• Ultra Low NOx: No
• Heating Capacity: 75.1 Kbtu/hr
• Energy Factor: 0.60
• Tank Capacity: 74 gal
• Dimensions: 26-1/2 in Dia x 61 in H
• Pressure Rating: 150 psi
• Recovery Rate: 81 gph at 90 deg F Rise
• Tall or Short: Short
• Water Connection: 1 in
• Brand: State Industries
• Package Width: 29.25 in
• Package Height: 60.38 in
• Package Length: 33 in
• Manufacturer: A. O. Smith
