State Water Heaters GS6-50-YBDS ProLine XE 50-Gallon 40000 BTU

Product Description

The STATE WATER HEATERS GS6-50-YBDS ProLine XE direct vent gas water heater draws air from outside, preventing issues from poor indoor ventilation. With a 50-gallon tank and 40,000 BTU gas burner, it delivers a 77-gallon first hour rating and a 43-gallon per hour recovery rate. The Green Choice burner reduces NOx emissions by up to 33% and meets Low NOx requirements.

• Delivers a 77-gallon first hour rating
• 40,000 BTU input direct vent design delivers up to 0.66 Uniform Energy Factor
• Green Choice Gas Burner design reduces NOx emissions by up to 33%

Product Highlights

This water heater features Blue Diamond glass tank lining, CoreGard anode rod, and DynaClean system for longevity and efficiency. It is FVIR compliant with a push-button Piezo ignitor and LED indicator.

Product Information

Standard Information

• Brand: STATE WATER HEATERS
• Manufacturer Part Number: GS6-50-YBDS
• Country of Origin: US

Technical Specifications

• Nominal Gallon Capacity: 50 Gallons
• Rated Storage Volume: 48 Gallons
• UEF: 0.66
• Maximum BTUs: 40,000
• Power Source: GAS
• T&P Relief Valve: Yes
• Water Connection Location: TOP
• Water Connection Size: 0.75"
• Emissions: Low NOx
• First Hour Rating: 77 Gallons
• ASME Certified: No
• Blanket Included: No
• Destination Country: US
• Flue Diameter: 4.00
• Fuel Source: NATURAL
• Height to T&P: 51.75
• Ignition Type: Piezo Pushbutton
• Installation Type: INDOOR
• Application: RESIDENTIAL
• Side Loop: No
• Type: Water Heater
• Height: 72.6"
• Diameter: 22"
• Vent Type: Direct Vent
• Height to Gas Valve: 14.24"
• Applicable Standard: ANSI Z21.10.1/CSA 4.1, ASHRAE/IES 90.1, UBC, CEC, HUD, EPCA
• Burner Type: Green Choice Low NOx
• Draft Hood Outlet/Vent Size: 3 Inch or 6 Inch
• Drain Valve Details: Solid Brass, Tamper Resistant, Enhanced Flow, Ball Type
• GPH Recovery: 43 GPH at 90 Deg F
• Gas Type: Natural
• Inclusions/Features: Intelligent Control Logic, LED Status Indicator, Gas Burner, Self-Cleaning Dip Tube, Coregard Anode Rod, Heat Trap Nipple
• Inlet/Outlet Connection: 3/4 Inch Male Threaded
• Input Supply Rating: 40000 BTU/Hour
• Insulation Details: 2 Inch Thickness Foam
• Item: Natural Gas Direct Vent Water Heater
• Relief Valve Details: CSA/ASME T and P Relief Valve
• Tank Capacity: 50 Gallon
• Tank Dimensions: 22 Inch Diameter x 59 Inch Height
• Tank Height Including Draft Hood: 73 Inch
• Venting Type: Direct, Co-Axial
• Model: State GS6-50-YBDS-300
• Capacity: 50 gallons
• Fuel Type: Natural Gas
• Venting: Direct Vent
• BTU Input: 40,000
• Energy Factor (UEF): 0.66
• Water Fittings: 3/4-inch
• Gas Fittings: 1/2-inch
• Tank Size (Gallons): 50
• Building Type: Residential
• Water Heater Height (inches): 59
• Diameter/Width (inches): 22
• Water Inlet Size: 3/4 Male
• Gas Connection (inches): 1/2
• Height Including Draft Hood (inches): 73
• Approximate Weight (pounds): 200
