Star Pipe Products FLBD06T Blind Flange 250 PSI 6 Inch

Product Description

The Star Pipe Products FLBD06T is a full body blind flange designed for use in various piping applications. Made from ASTM A536 prime coated ductile iron, this flange provides strength and durability. It features a pressure rating of 250 PSI and is equipped with a red prime coated cement lining, enhancing its performance in demanding environments.

• Six-inch nominal size with an eleven-inch outside diameter
• Standard flange thickness of one inch
• Designed to meet ANSI/AWWA standards

Product Highlights

This blind flange is ideal for waterworks and mechanical joint fittings, providing reliable sealing solutions.

Product Information

Standard Information

• Manufacturer: Star Pipe Products
• UPC: Not available

Technical Specifications

• Nominal Size: 6 Inch
• Flange Outside Diameter: 11 Inch
• Flange Thickness: 1 Inch
• Raised Face Diameter: 6 Inch
• Bolt Circle Diameter: 0.88 Inch
• Body Material: ASTM A536 Prime Coated Ductile Iron
• Liner Material: Red Prime Coated Cement
• Pressure Rating: 250 PSI
• Applicable Standards: ANSI/AWWA C104/A21.4, ANSI/AWWA C110/A21.10, ANSI/AWWA C153/A21.53, ANSI B16.1, NSF 61/372, UL, ULC, FM
• Type: Import, Full Body, Blind
• Tap Size: 2 Inch Threaded
