Star Pipe Products FLBD04T 4 Inch Ductile Iron Blind Flange 250 PSI

Product Description

The Star Pipe Products FLBD04T is a blind flange made from ASTM A536 ductile iron and features a nominal size of four inches. This flange has a flange outside diameter of nine inches and a thickness of 0.94 inches. It is rated for a pressure of 250 PSI which makes it suitable for various industrial applications.

• Material: Ductile Iron
• Pressure Rating: 250 PSI
• Flange Type: Blind, Full Body, Tapped

Product Highlights

This blind flange is designed to meet ANSI/AWWA C110/A21.10 standards, offering reliability and strength in piping systems. The interior is cement lined with an asphaltic seal coat, while the exterior is coated with red prime for enhanced durability.

Product Information

Standard Information

• Manufacturer: Star Pipe Products
• UPC: N/A

Technical Specifications

• Flange Outside Diameter: 9 Inch
• Flange Thickness: 0.94 Inch
• Nominal Size: 4 Inch
• Pressure Rating: 250 PSI
• Applicable Standard: ANSI/AWWA C110/A21.10, UL/ANSI/NSF 61 and 372
• Weight: 16 Pound
• Package/Shipping Quantity: 160 per Crate
