Square D XMLGM01D23 Analog Pressure Sensor 24 Vdc

Product Description

The SQUARE D XMLGM01D23 is an analog control circuit pressure sensor designed for industrial and commercial fluid system monitoring. It operates on 24 volts DC and delivers a 4-20 milliamp output signal, making it compatible with standard PLC and control circuit inputs. The sensor measures pressure down to -1 bar and connects via a 1/4-18 NPT male fluid port. With an IP66 and IP67 ingress protection rating, the XMLGM01D23 resists dust intrusion and temporary water immersion. Its shock-resistant and vibration-resistant construction suits demanding installation environments. Licensed electricians, instrumentation technicians, and controls specialists are the primary installers of this sensor type.

The XMLGM01D23 is suited for control circuit applications involving air, fresh water, hydraulic oil, and corrosive fluid service. Its analog 4-20 mA output integrates directly into process control loops and SCADA systems. The sensor measures 2.7 inches in length and 0.9 inches in diameter, fitting into compact manifold and inline mounting configurations. Operating temperature range spans 5 degrees F to 185 degrees F, covering a broad range of indoor and light industrial environments. This unit ships in a package quantity of one.

Key Features

• 24 VDC input with 4-20 mA analog output for direct integration with control circuits and PLCs
• -1 bar pressure range for vacuum and low-pressure system monitoring
• IP66 and IP67 rated for dust-tight and water-immersion resistance
• Shock-resistant and vibration-resistant construction for demanding service conditions
• 1/4-18 NPT male fluid connection with 3-pin M12 male electrical connector
• Measurement accuracy of 0.30 percent for reliable process feedback
• RoHS compliant with CE, CSA, UL 508, and EAC certifications

Compatibility

Rated for use with air, corrosive fluid, fresh water, and hydraulic oil service. Designed as an OEM-style control circuit pressure sensor for industrial fluid monitoring and process control applications.

Installation Notes

Installation should be performed by a licensed electrician or qualified instrumentation technician in accordance with NEC requirements and local codes. De-energize the control circuit and depressurize the fluid system before connecting or disconnecting the sensor. The 3-pin M12 male electrical connector should be fully seated and locked before restoring power. Do not exceed the rated operating temperature range or use with fluids not listed in the compatibility specifications.
