Square D XMLG006D23 Analog Pressure Sensor 87 Psi 24 Vdc

Product Description

The SQUARE D XMLG006D23 is an analog control circuit pressure sensor rated for 87 psi and 24 volts DC. It outputs a standard 4-20 mA signal, making it compatible with most industrial and HVAC control systems that accept analog current-loop inputs. The sensor uses a 1/4-18 NPT male fluid connector and a 3-pin M12 male electrical connector. It measures 2.7 inches long and 0.9 inches in diameter, and weighs 0.29 pounds. Rated IP66 and IP67, the housing resists water ingress and dust intrusion. It is designed for installation by licensed HVAC technicians, electricians, or controls specialists working on pressure-sensing applications in control circuits.

This sensor is suited for residential and commercial applications where reliable pressure monitoring is required. It is rated for use with air, corrosive fluid, fresh water, and hydraulic oil, covering a wide range of system types including HVAC controls, fluid handling systems, and hydraulic equipment. Operating temperature range spans 5 degrees F to 185 degrees F, making it appropriate for installations in both cold and high-heat environments. Its shock-resistant and vibration-resistant construction suits installations in mechanically demanding locations such as rooftop units, compressor skids, or equipment rooms with sustained vibration.

Key Features

• 87 psi pressure range with 0.30 percent measurement accuracy
• 4-20 mA analog output signal for direct integration with control circuit inputs
• IP66 and IP67 ingress protection rating for water and dust resistance
• Shock-resistant and vibration-resistant construction for demanding install environments
• Compatible with air, corrosive fluid, fresh water, and hydraulic oil media
• Certified to UL 508, CSA C22.2 No. 14, CE, EAC, and RoHS standards

Compatibility

Designed for control circuit pressure-sensing applications using air, corrosive fluid, fresh water, or hydraulic oil as the process medium. Suitable for systems requiring a 4-20 mA analog signal input and a 1/4-18 NPT male fluid connection with a 3-pin M12 male electrical interface.

Installation Notes

Installation should be performed by a qualified electrician or licensed HVAC controls technician. De-energize the control circuit and depressurize the fluid system fully before making any connections. Apply appropriate thread sealant to the NPT fitting per IPC or IFGC guidelines and do not overtighten the fluid connector. Verify the control system input is configured for a 4-20 mA current-loop signal before powering up.
