Square D VCF02 Cam Disconnect Switch Fused 690VAC 3 Pole

Product Description

The SQUARE D VCF02 is an enclosed, fused cam disconnect switch rated for 690 volts AC. It is designed to isolate electrical circuits in industrial and commercial distribution systems, providing a safe means of de-energizing equipment for maintenance or service. The switch features a 3-pole, 3-wire configuration with a 3NO contact form. It ships complete with a handle and switch assembly in a compact housing measuring 2.91 inches in overall height and 2.36 inches in width. Licensed electricians and industrial maintenance technicians are the primary installers of this device.

The VCF02 is suited for use in panel boards, motor control centers, and industrial enclosures where a fused disconnect is required. Its dual ingress protection ratings of IP20 and IP65 make it adaptable to a range of installation environments, from indoor panels to areas requiring a higher degree of protection against dust and water ingress. The NEMA ratings of 1 and 12 further support its use in general-purpose and dust-tight enclosures.

Key Features

• Fused enclosed cam disconnect design for circuit isolation and overcurrent protection
• 3-pole, 3-wire, 3NO configuration rated at 690 volts AC
• Dual ingress protection ratings: IP20 and IP65
• NEMA 1 and NEMA 12 rated enclosure compatibility
• Includes handle and switch assembly
• Multi-standard certifications: CSA, GL, IEC 60947-3, UL

Compatibility

Designed as an OEM-style replacement or new-installation fused cam disconnect switch for industrial and commercial electrical distribution panels and motor control centers requiring a 690VAC, 3-pole enclosed disconnect.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. Always de-energize and lock out the upstream circuit before mounting or wiring the disconnect switch. Verify that the enclosure rating of the installation location is compatible with the switch's IP and NEMA ratings prior to final mounting. Follow IEC 60947-3 guidelines where applicable for industrial switchgear installations.
