Square D VCD0 Cam Disconnect Switch Enclosed Fused 690VAC

Product Description

The SQUARE D VCD0 is an enclosed, fused cam disconnect switch rated for 690 volts AC. It provides a positive means of isolating electrical circuits in industrial and commercial power distribution systems. The switch features a 3-pole, 3-wire configuration with normally open (3NO) contacts and includes a built-in handle for manual operation. With dual ingress protection ratings of IP20 and IP65, it suits both standard indoor panel applications and environments requiring a higher degree of protection against dust and water. Licensed electricians and industrial maintenance technicians are the typical installers of this component.

This cam disconnect switch is suited for industrial control panels, machine tool wiring, and commercial power distribution equipment where a fused, lockable isolation point is required. The enclosed design and NEMA 1 and NEMA 12 ratings make it appropriate for general-purpose indoor installations and applications where protection from dripping liquids or dust is needed. It is also UL Certified and CSA Certified, making it compliant for use in North American installations governed by the NEC.

Key Features

• Enclosed fused design with integrated handle for positive manual isolation
• Rated 690 volts AC with 3-pole, 3NO contact configuration
• Dual ingress protection ratings: IP20 and IP65
• NEMA 1 and NEMA 12 enclosure ratings for indoor general-purpose and dust-resistant applications
• UL Certified, CSA Certified, GL listed, and compliant with IEC 60947-3
• Compact form factor suitable for panel integration

Compatibility

Designed as an OEM-style enclosed fused cam disconnect switch for industrial control panels and commercial power distribution systems requiring a 690VAC rated 3-pole isolation device.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the upstream circuit before mounting or wiring this disconnect switch. Verify that the supply voltage and ampacity are within the rated specifications of the switch before restoring power. Do not exceed the rated voltage or attempt to use this switch as a load-break device outside of its rated application.
