Square D VCCD1 Cam Disconnect Switch 690VAC 3 Pole

Product Description

The SQUARE D VCCD1 is a fused, enclosed cam disconnect switch rated for 690 volts AC service. It is a 3-pole device with a 3NO contact form, designed to provide a visible means of disconnect and overcurrent protection in industrial electrical distribution systems. The switch ships with a handle and shaft extension included. At 0.81 pounds, it is compact enough for panel or enclosure integration. Licensed electricians and industrial maintenance technicians are the primary installers of this device. The dual ingress protection ratings of IP20 and IP65 make it suitable for both standard and wash-down-adjacent environments.

The VCCD1 is intended for industrial and commercial electrical applications where a fused cam-style disconnect is required. Its NEMA 1 and NEMA 12 ratings cover general-purpose indoor use as well as protection against dust and dripping non-corrosive liquids. The switch is engineered to IEC 60947-3 standards and carries both UL and CSA certifications, making it appropriate for North American and international installations. It is commonly installed in motor control circuits, machinery disconnect applications, and panel board assemblies where code-required lockout capability is needed.

Key Features

• Fused 3-pole design provides both disconnecting means and overcurrent protection in one assembly
• Rated 690 volts AC with 3NO contact configuration for direct switching applications
• Dual IP ratings: IP20 and IP65, supporting varied indoor environment requirements
• NEMA 1 and NEMA 12 rated enclosure for general-purpose and dust-protected installations
• Includes handle and shaft extension for complete, ready-to-install assembly
• Certified to IEC 60947-3, UL, CSA, and GL standards for broad compliance coverage

Compatibility

Designed as an OEM-style cam disconnect switch replacement for industrial electrical enclosures and motor control applications requiring a fused 3-pole, 690VAC-rated disconnect meeting IEC 60947-3, UL, and CSA requirements.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lockout-tagout all upstream circuits before mounting or wiring the switch. Verify the enclosure rating is appropriate for the installation environment before final mounting. Do not exceed the rated voltage or pole configuration for the application.
