Square D V01 Cam Disconnect Switch 690VAC 3 Pole Fused

Product Description

The SQUARE D V01 is a fused, enclosed cam disconnect switch rated for 690VAC three-phase service. It provides a manual means of isolating electrical circuits in industrial and commercial installations. The switch features a 3NO contact form across three poles and three wires, making it suitable for controlling and de-energizing three-phase loads. With an IP20 ingress protection rating, the enclosure guards internal components against solid objects. Overall dimensions are 2.91 inches in height, 2.17 inches in width, and 2.36 inches in depth. Licensed electricians and industrial maintenance technicians are the primary installers of this device.

This cam disconnect switch is designed for three-phase electrical systems in commercial and industrial environments. Typical applications include motor disconnect service, machine isolation panels, and distribution switchboards where a fused manual disconnect is required by code. The compact enclosed housing allows integration into existing enclosures or control panels where space is limited. Its multi-standard certification makes it suitable for installations requiring compliance across North American and international electrical standards.

Key Features

• Fused design provides overcurrent protection at the disconnect point
• Rated for 690VAC three-phase operation
• 3NO contact form with 3 poles and 3 wires
• IP20 ingress protection rating guards against solid object intrusion
• Certified to CSA, GL, IEC 60947-3, and UL standards
• Compact enclosed form factor at 2.91 x 2.17 x 2.36 inches

Compatibility

Designed as an OEM-style replacement or new-installation cam disconnect switch for three-phase enclosed fused disconnect applications rated up to 690VAC.

Installation Notes

Installation must be performed by a qualified licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the upstream circuit before installing or servicing this disconnect switch. Verify that the supply voltage and phase configuration match the switch rating before applying power. Do not exceed the rated voltage or attempt to modify the internal fusing arrangement.
