Square D QOUQ260 Miniature Circuit Breaker 2-Pole 60 Amp 120/240 Volt

Product Description

Engineered for reliability and efficiency, the Square D QOUQ260 Miniature Circuit Breaker is a 2-pole, 60 Amp breaker that operates on both 120 and 240 Volt systems. Designed for optimal performance in OEM applications, this unit features Quick Connection technology, ensuring robust overcurrent protection and easy manual circuit disruption capabilities.

• Dual voltage support for versatile use in varied electrical setups.
• Visi-Trip indicator for rapid detection of circuit breaker trips.
• Flexible mounting options: flush, surface, or DIN rail.

Product Highlights

This breaker is constructed to provide a manual means to open a circuit and is equipped with a common trip mechanism for simultaneous pole tripping. Its compact design supports quick installation and easy operation in confined spaces. Certified under UL, CSA, and certified for reverse connection, the breaker adheres to stringent safety standards.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Square D
• Model: QOUQ260

Technical Specifications

• Dimensions: Width: 1.5 inches, Height: 4.05 inches, Depth: 2.95 inches
• Mounting: Unit Mount
• Number of Poles: 2 Pole
• Voltage: 120/240V AC, 48V DC
• Amperage: 60 Amp
• Terminal Connection: Slotted Box Lug
• Warranty: 18 months
• Country of Origin: Mexico
