Product Description
The Square D QOU330 is a miniature circuit breaker with a rating of thirty amps and two hundred forty volts. This breaker is built for OEM applications and is suitable for both AC and DC electrical systems. It serves two main functions: providing overcurrent protection and allowing for manual circuit opening.
- Operates in any position.
- Includes lugs at both ends for cable-in/cable-out construction.
- Fully tested, UL Listed, and CSA certified for reverse connection without restrictive line/load markings.
Product Highlights
This circuit breaker features a common tripping mechanism across all poles and Visi-Trip technology for easy trip detection.
Product Information
Standard Information
-
Brand: Square D
-
Manufacturer: Schneider Electric
Technical Specifications
-
Catalog Number: QOU330
-
Voltage: 120 Volt
-
Amperage: 30 Amp
-
Number of Poles: 3 Pole
-
Height: 4.05 inches
-
Width: 2.25 inches
-
Depth: 2.95 inches
-
Warranty Length: 18 months
-
Country of Origin: Mexico
-
Interrupt Rating: 10 kAIC
