Square D QOU2203100 Mini Circuit Breaker 20A 2 Pole 10kA

Product Description

The Square D QOU2203100 Mini Circuit Breaker is a reliable option for circuit protection. This model features a two-pole configuration rated at 20 amps and 240 volts AC. It provides essential overcurrent protection for different applications, including residential and commercial installations.

• Two-pole thermal magnetic design for reliable performance
• Rated for 20A and 240 VAC with a ten kA interrupt capacity
• Versatile mounting options including DIN rail and surface mount

Product Highlights

This circuit breaker is ideal for installation in OEM applications, providing protection on both AC and DC systems. Its trip-free toggle mechanism ensures quick response and visual trip indication, enhancing user safety and system reliability.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Type: Miniature circuit breaker
• Amperage: 20 Amp
• Voltage: 120/240 V AC
• Interrupt Rating: 10 kAIC
• Number of Poles: 2 Pole
• Dimensions: Height - 4.05 inches, Width - 1.5 inches, Depth - 2.95 inches
• Mounting Type: Unit Mount
• Country of Origin: Mexico
