Square D QOB2401021 Miniature Circuit Breaker 40 Amp 120/240 Volt

Product Description

The Square D QOB2401021 is a reliable two-pole, thermal magnetic miniature circuit breaker designed for overcurrent protection in various electrical systems. This particular model is rated for forty amps at 120/240 volts and features bolt-on mounting. It includes a shunt trip for enhanced functionality.

• Two-pole design for AC and DC systems.
• Features VisiTrip indication for circuit breaker status.
• UL listed under UL File E84967 and CSA Certified.

Product Highlights

QOB2401021 offers essential features for circuit protection including quick make, quick break action, and visual trip indication, ensuring effective electrical safety.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Square D

Technical Specifications

• Current Rating: 40 Amps
• Voltage Rating: 120/240 Volt AC
• Breaking Capacity: 10 kA
• Number of Poles: 2
• Dimensions: 2.91 inches (length) x 2.25 inches (width) x 3.12 inches (height)
• Weight: 0.435 kg
• Wire Size: AWG 8 to AWG 2
• Mounting Type: Bolt-on
• Temperature Rating: -40 to 40 degrees Celsius
