Square D QOB235 Miniature Circuit Breaker 35 Amp 120/240 Volt

Product Description

The Square D QOB235 Miniature Circuit Breaker is designed to provide overcurrent protection for AC and DC systems. This two-pole breaker is rated at thirty-five amps, operating at one hundred twenty to two hundred forty volts. It features a trip-free toggle mechanism that ensures quick make and quick break actions, giving positive handle indication. The VisiTrip feature provides a visual alert when the breaker has tripped. Ideal for use in various applications where protection of electrical circuits is necessary.

• Rated at 35 Amperes
• UL Listed and CSA Certified
• 10kA breaking capacity with bolt-on mounting

Product Highlights

This circuit breaker is suitable for a variety of installations, offering features such as quick installation and exceptional reliability.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: QOB235
• Voltage: 120/240 Volt
• Amperage: 35 Amp
• Number of Poles: 2 Pole
• Depth: 74 mm
• Width: 38 mm
• Height: 79 mm
• Breaking Capacity: 10kA
• Mounting Type: Bolt-on
• Warranty: 18 months
• Country of Origin: Mexico
• GTIN: 00785901368298
• UPC: 785901368298
