Product Description
The Square D QOB2125VH is a 2-pole thermal magnetic circuit breaker that provides overcurrent protection and switching on AC and DC systems. It features an over center, trip-free toggle mechanism with quick make, quick break action and positive handle indication, as well as VisiTrip trip indication. Rated at 125A at 120/240VAC with a 22kA breaking capacity and bolt-on mounting.
- Overcurrent protection
- Switching on AC and DC systems
- VisiTrip trip indication
- 22kA breaking capacity
Product Highlights
This Square D circuit breaker is UL Listed and CSA Certified, suitable for appliance and lighting applications, and designed for use with NQ or NQOD Panelboards.
Product Information
Standard Information
-
Brand: SQUARE D
-
Manufacturer Part Number: QOB2125VH
-
Country of Origin: Mexico
Technical Specifications
-
Type: Branch
-
Brand: Square D
-
Depth: 74 mm
-
Width: 38 mm
-
Height: 89 mm
-
Length: 2.91 Inch
-
Current: 125 Amp
-
Voltage: 120/240 VAC
-
Amperage: 125 Amp
-
Sub Brand: QO
-
Wire Size: AWG 4...300 kcmil copper or aluminium
-
Product UPC: 78590112065
-
12-Digit UPC: 785901120650
-
Applications: HACR rated
-
Mounting Type: Bolt-on
-
TC Connection: Box lugs
-
Certifications: CSA,UL Listed
-
Conductor Size: 4 AWG-300 kcmil
-
Number of Poles: 2
-
Interrupt Rating: 22 kAIC
-
Country of Origin: Mexico
-
Line Rated Current: 125 A
-
Circuit Breaker Type: Standard
-
Short Circuit Current: 22 kA
-
Manufacturer: Schneider Electric
-
UPC: 785901120650
-
GTIN: 00785901120650
-
Installation: Bolt-On
-
Application: Appliance, Lighting
-
Used On: NQ Series Panelboard
-
Approval: UL, CSA
-
Frame Type: Q
-
Tripping Method: Thermal Magnetic
-
Includes: Visi-Trip Indicator
-
Poles: 2 Pole
-
Phase: 1 ph
-
Connection: Box Lug Connection
-
Mounting: Bolt-On Mounting
-
Temperature: 40 deg C
-
Manufacture: Square D
-
Frequency: 50/60 Hz
-
Trip Type: Thermal/Magnetic Trip
-
Material: Fiberglass Filled Thermoset
-
Range Of Product: QO
-
Product Or Component Type: miniature circuit-breaker
-
Circuit Breaker Application: HACR rated
-
Mounting Mode: bolt-on
-
Poles Description: 2P
-
Electrical Connection: box lugs
-
[Ue] Rated Operational Voltage: 120/240 V AC || 240 V AC || 120 V AC
-
Tightening Torque: 5.6-5.6 N.m
-
Number Of Spaces Required: 2
-
Breaking Capacity: 22 kA 120/240 V AC || 22 kA 240 V AC || 22 kA 120 V AC
-
Awg Gauge: AWG 4...300 kcmil copper or aluminium
-
Product Certifications: UL Listed || CSA
-
Ambient Air Temperature For Operation: 40 °C
-
System Voltage: 120 V AC, 120/240 V AC, 240 V AC
-
Ratings: HACR rated
-
Inturrupt Rating: 22 kA at: 120/240 V AC 50/60 Hz, 22 kA at: 240 V AC 50/60 Hz, 22 kA at: 120 V AC 50/60 Hz
-
Number of Panel Spaces: 2
-
Ambient Rating: 104 Degree F (40 Degree C)
