Square D QO330MQ150 Load Center Main Breaker 150A 30 Spaces 30 Circuits NEMA 1

Product Description

The Square D QO330MQ150 is a robust load center designed for convenience and safety in electrical systems. This three-phase load center includes a main breaker rated at 150A, providing efficient circuit protection for residential and industrial applications. It features 30 spaces for circuit breakers, enabling flexible circuit management and organization.

• Rated for three-phase operation with 30 circuits.
• Tin-plated copper bus ensures high conductivity and durability.
• Includes a NEMA 1 enclosure suitable for indoor installations.

Product Highlights

This load center supports various configurations, including traditional and plug-on neutral setups. It accommodates QO breakers, ground fault interrupters, and more, making it a versatile choice for different electrical applications.

Product Information

Standard Information

• Brand: Square D
• MPN: QO330MQ150

Technical Specifications

• UPC: 785901290537
• Phase: 3-Phase
• Amperage Rating: 150 Amperes
• Voltage Rating: 208Y/120 VAC
• NEMA Rating: NEMA 1
• Number of Spaces: 30
• Interrupt Rating: 25 Kiloamperes
• Enclosure Material: Welded sheet steel
• Dimensions: 14.25 inches width x 39.37 inches height
• Weight: 25.63 pounds
