Square D QO290VH Miniature Circuit Breaker 90 Amp 120/240 VAC

Product Description

The Square D QO290VH is a 2-pole miniature circuit breaker designed for applications requiring reliable circuit protection. This unit operates at 90 amperes and is suitable for 120/240 VAC systems. It features a quick make and break toggle mechanism that ensures enhanced safety.

• 90 amp capacity for efficient circuit protection.
• UL listed for reliable performance and compliance.
• Plug-in mounting for easy installation in load centers.

Product Highlights

The QO290VH circuit breaker ensures overcurrent protection for AC and DC systems. It includes a trip free toggle mechanism and VisiTrip indication for easy identification.

Product Information

Standard Information

• Brand: Square D
• MPN: QO290VH

Technical Specifications

• Catalog Number: QO290VH
• Current Rating: 90 Amp
• Voltage Rating: 120/240 VAC
• Number of Poles: 2 Pole
• Breaking Capacity: 22 kAIC
• Mounting Type: Plug-in
• Operating Temperature: -40 to 40 Degrees C
• Country of Origin: Mexico
