Square D QO2701021 2-Pole 70 Amp 120/240 Volt Plug-On Thermal Magnetic Miniature Circuit Breaker

Product Description

The Square D QO2701021 is a 2-pole, 70 amp thermal magnetic miniature circuit breaker that provides reliable overcurrent protection for both AC and DC systems. This circuit breaker features an over center, trip free toggle mechanism designed for quick make and break action. The unit includes VisiTrip indication for visual feedback if a trip occurs, ensuring quick identification of issues. The QO circuit breaker is rated for 70 amps at 120/240 volts and has a breaking capacity of 10kA, suitable for various applications in power distribution.

• Rated for 70A at 120/240VAC
• Includes AC shunt trip
• UL Listed and CSA Certified for safety

Product Highlights

The QO series is designed for maximum safety and functionality in electrical distribution systems. Its plug-in mounting type makes for easy installation in various panels.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: QO2701021
• Current Rating: 70 Amp
• Voltage Rating: 120 Volt / 240 Volt
• Amperage Rating: 70 Amp
• Material: Fiberglass
• Mounting Type: Plug-in
• Number of Poles: 2 Pole
• Warranty Length: 18 months
